Product SKU: APC-ABLE-LNM3000x2-DC-L24-KB

Build Your Own Gate Opener Kit with Italian-made APC Able 3000x2 Heavy-Duty Linear Actuators. Double Swing Remote Control Driveway Gates Automatic Opening/Closing 24V System for Max 6m Gates (3m or 600kg for Each Gate) With Adjustable Built-In Stop and Feature-Rich Logico Control Box. APC Gate Automation Systems for Australian homes are built to withstand harsh conditions, with local support and warranty.

Upload Images (Max. 5 images can be uploaded)

Upload
no file chosen

  • Extra 10% Off

    coupon EASTER24

Build Your Own Gate Opener Kit with Italian-made APC Able 3000x2 Heavy-Duty Linear Actuators. Double Swing Remote Control Driveway Gates Automatic Opening/Closing 24V System for Max 6m Gates (3m or 600kg for Each Gate) With Adjustable Built-In Stop and Feature-Rich Logico Control Box. APC Gate Automation Systems for Australian homes are built to withstand harsh conditions, with local support and warranty.

Product SKU: APC-ABLE-LNM3000x2-DC-L24-KB

  •  In Stock

Get More Info..
Free Shipping Free Shipping

Kit Price:

$1,999.00 $2,199.00 APC Automotion Plus Sale

  • Or in 4 payment of $499.75 with afterpay info

  • Automatic Double Gate Opener 24V System. Max 3m or 600kg for Each Gate. Adjustable Built-In Stop.

  • Kit Includes

    01 APC Able 3000 Heavy Duty Linear Actuator, Italian Made Swing Gate Opener Motor with Adjustable Built-In Stop for Automatic Gate Opener 24V System. Max 3m or 600kg per gate. (QTY: 2)
    02 Cable for Swing Gate Opener Motor ( 2 Core 2mm Non-Shielded Cable 3m / 6m ) (QTY: 1)
    03 Pair of Mechanical Limit Stop for Each APC-able Linear Actuators Suitable for Opening and Closing Position (QTY: 2)
    04 APC Logico 24V Feature Rich Control Box Kit with Internal Transformer and Power Lead (QTY: 1)
    05 APC Four Button Keyring Remote (QTY: 2)
    06 Two FREE Sunvisor Remote Controls (Promotion) with every Electric Gate Automation Kit order. (QTY: 2)
  • Customise Kit
  • Add-On Items
  • Product Information

Customise your Kit

Add-On Items (Discounted when purchased along with this Kit)

Product Information

Italian Made Double Swing Gate Opener | Linear Actuator for Automatic Driveway Gates

Packing a punch, the "APC Able 6000" system delivers 2000N of thrust, enabling it to operate gates up to 600kg or 3m in length (for each gate leaf). With a built-in adjustable mechanical opening stop (an optional add-on mechanical closing stop), the system offers versatile stopping positions.

24V Automatic Double Swing Gate Motor. "APC Able 6000" Electromechanical actuator for swing gates with each leaf up to 3m in length (for each gate).





Italian Made Double Swing Gate Actuator Overview

Characteristics

  • Equipped with an opening mechanical limit stop
  • Mechanical closing stop accessory
  • Single version for both right and left leaves
  • Adjustable brackets for quick engine installation
  • Aluminum frame
  • Unlocking the handle with the protected lock
  • Plug-in connector for electrical connections



Italian Made Swing Gate Automation Installation Geometry



Italian Made Double Swing Gate Opener System | Automatic Gate Motor Specifications

Thrust 2000N

Motor Voltage

24v DC

Manual override

Via override key supplied

Working temperature

-20° - +55°

Gates size

3m max for each gate

Gate weight

600kg max for each gate

Italian-Made Swing Gate Motor System Capacity

Maximum Gates Leaf Length: 3 M*

Maximum Gates Leaf Weight: 600 Kg*

(*for each gate)







Feature Rich and Highly Versatile Control Box



The Proteous Logico 24 Control Unit provides the the latest enhanced technology and rich feature set of full programmability using the onboard intuitive LCD interface suitable for the novice user with simple setups all the way to 100% commercial sites with its advance features and its high duty cycle system.

There is no function or feature that this system cannot perform. See the full details below.

System Features

80% Duty Cycle (Can operate for up to 48 Minutes of every 60 minutes)
Full Feature MODERN Programmability by LCD Display (No DIP Switches or Dials)
Automatic learning of gate travel limits
Completly adjustable slowdown points
Configurable pedestrian operation travel amount which can be operated by remote, keypad, button, APP control (module available) and induction loop
Fast and Slow Speeds points are adjustable along with there power
Simple ONE PRESS full feature remote Ultra High Security Rolling Code learning system (and service free remote learning options)
Ultimate Auto close settings adjustable from 5 seconds to 20 Minutes
Party Mode System to keep gates opened when configured for use with the automatic close feature
Five underside cable entry with glands
Pre-Wired and ready to plug into a regular 10A power point or can be hardwired if preferred
All installation connections are low voltage (except in the case of high voltage driveway lights(low voltage can be used))

Special Features

Energy Saving Mode (5mA Standby Current)
Optional battery backup system
Standalone low voltage/high voltage driveway light control by remote (completely separate to the safety light)
Soft Start/Soft Stop (Ramping feature) with adjustable cut in points
Direct electric lock connection
Induction Loop Compatible for auto opening or as a safety device
Supports programmable timers

Safety Features

Adjustable Over current adjustments
Supports encoder motors and limit switch motors
Safety Sensor connection input configurable for open and/or closing
Supports Safety Edges
Automatic Courtesy Light Output (Blinking or Static illumination) with adjustable pre-operating courtesy times

Simple to use LCD interface

Control Board Overview



Accessories Compatibility and Controlling Options

Constant DC Accessories Output
Open/Stop/Close Inputs for Full Gate Operation and Pedestrian Gate Operation
Remote controls
Induction Loops
Weekly Timers
Entry and Exit push button with isolation key switches (Wired and Wireless Options Available)
Keypads (Wired and Wireless Options Available)
Exit/entry sensors
Intercom system with dry contact output
Automatic switching timer
WiFi Control System (App Based Control)
GSM Control Systems (Mobile Call/SMS based Control)



Remote Features

Specifications

Transformer 24V AC
Rectification In Box Rectifier
Motor Output Voltage 24v DC
Max Operating Power 250 Watts (Accesories + Running Motors)
Max. Accesories Load 7W
Control Board Duty Cycle 80%
Working temperature -20° - 50°
RF APC Rolling code 433.92mhz
Auxiliary Inputs 0V Momentary Pulse
Accessories Voltage 24V DC
Operator Inbuilt Safety Over current + Encoder Sensitivity



Your Customised Kit Includes:

No Changes.
        • Kit Quantity:
          • 1

        • Your (Kit and Add-On) Price:

          $1,999.00
